特点/Features
1.线对板连接器具有灵活性和可靠性
Line to board connectors have flexibility and reliability
2.适用于小尺寸插接和安全端接
Suitable for small size insertion and safe termination
3.将导线连接到PCB，从而实现电路之间的连接
Connect wires to the PCB to achieve connections between circuits
规格参数/Specifications
电气特性 Electrical characteristics | 额定电流 Current rating | 3.0A Max |
额定电压 voltage rating | 250V DC | |
绝缘阻抗 Insulation impedance | 100mΩMin | |
绝缘耐电压 Insulation withstand voltage | 祥见具体产品规格 | |
电气寿命 Electrical life | 祥见具体产品规格 | |
机械/可靠性特性 Mechanical/reliability characteristics | 操 作 力 Operation force | 祥见具体产品规格 |
机械寿命 Mechanical life | 祥见具体产品规格 | |
使用温度 Service temperature | -25℃+85℃ | |
使用湿度 Operating humidity | ≤85%RH | |
可 焊 性 Weldability | 245℃±5℃ 3S | |
耐焊接热 Resistance to welding heat | 260℃±5℃ 3S |
