规格参数/Specifications
电气特性 Electrical characteristics | 额度负荷 Rating | 见具体产品规格 See detail spec |
接触阻抗 Contact impedance | ≤50mΩ | |
绝缘阻抗 Insulation impedance | ≥100mΩ DC250V | |
绝缘耐电压 Insulation withstand voltage | AC500V 1minute | |
电气寿命 Electrical life | 见具体产品规格 See detail spec | |
机械/可靠性特性 Mechanical/reliability characteristics | 操 作 力 Operation force | 见具体产品规格 See detail spec |
机械寿命 Mechanical life | 见具体产品规格 See detail spec | |
使用温度 Service temperature | -25℃+80℃ | |
使用湿度 Operating humidity | ≤85%RH | |
可 焊 性 Weldability | 245℃±5℃ 3S | |
耐焊接热 Resistance to welding heat | 260℃±5℃ 3S |
