特点/Features
1.FPC连接器具有水平和垂直方向以及多种锁定方式
FPC connectors have horizontal and vertical directions as well as multiple locking methods
2.FPC连接器具有0.3mm、0.5mm、0.8mm、1.0mm和1.25mm间距
FPC connectors have spacing of 0.3mm, 0.5mm, 0.8mm, 1.0mm, and 1.25mm
3.HUATN的FPC连接器完全符合RoHS和Reach
HUATN FPC connectors fully comply with RoHS and Reach
规格参数/Specifications
电气特性 Electrical characteristics | 额定电流 Current rating | 0.5A Max |
额定电压 voltage rating | 50V DC | |
绝缘阻抗 Insulation impedance | 500mΩMin | |
绝缘耐电压 Insulation withstand voltage | AC250V 1min | |
电气寿命 Electrical life | 祥见具体产品规格 | |
机械/可靠性特性 Mechanical/reliability characteristics | 操 作 力 Operation force | 祥见具体产品规格 |
机械寿命 Mechanical life | 祥见具体产品规格 | |
使用温度 Service temperature | -25℃+85℃ | |
使用湿度 Operating humidity | ≤85%RH | |
可 焊 性 Weldability | 245℃±5℃ 3S | |
耐焊接热 Resistance to welding heat | 260℃±5℃ 3S |
